Eagle One

A compact vehicle packed with features – ready to take flight!

The sleek, compact design of our Eagle One makes it versatile for all kinds of use and can be stored easily. This personal mobility vehicle is offered with a top or without a top, and also features other customizable options to make it your own.

  • eagle one horse
  • eagle one horse
  • eagle one horse

  • LOAD CAPACITY LBS

    500

  • SEATING CAPACITY

    2

  • SPEED MPH

    15

  • VOLTAGE

    36

Eagle One Features

  • Batteries: 12V Group 22NF AGM
  • Total Voltage: 36 Volts
  • Controller: 300A Fully Programmable
  • Motor: 36V DC 3HP Shunt
  • Transaxle Ratio: 12.375 : 1
  • Accelerator: Foot Control
  • Brakes: Dual rear wheel drum with Electro Mechanical Holding Brake and regenerative assist
  • Suspension: None
  • Steering: Tie Rod
  • Seating: Bench seat with fold down back
  • Seating Capacity: 2
  • Load Capacity: 350 lbs
  • Speed: Up to 15 mph
  • Chassis: Welded tubular E-coated & powder coated steel
  • Body: ABS
  • Tires: 16 x 6.5 x 8 Turf
  • Weight W/Batteries: 480 lbs
  • Length: 66"
  • Width: 37"
  • Height: 38"
  • Wheel Base: 45"
  • Ground Clearance: 3.5"
customize

Customize your Vehicle!

Choose from any of our options available to make your Eagle One just the way you want it! Ask a representative about our customizable options!
